Enemies / EnemiesNoSync

This module contains the enemy descriptors. The name of the module can be either Enemies or EnemiesNoSync, but never both at the same time. The choice of which to use depends on if you want your difficulty to be pubbable, that is, to be played with players that do not have CD2 installed:

• Some CD2 features require being replicated to the clients, such as the Scale enemy control or the customization of enemy looks (materials). Enemies can replicate these characteristics to players, but in exchange it will force the clients to use CD2 or they will suffer a disconnect upon mission start.
• EnemiesNoSync doesn't do replication to clients. A difficulty with EnemiesNoSync is compatible with all clients, regardless of whether they use CD1, CD2 or nothing at all. When you use EnemiesNoSync you are implicitly stating that you didn't use any features that require replication.

To see which features require the Enemies module, please check the following guide by @Spy: On Pubbing With CD2.

Descriptor controls

Name	Type
CanBeUsedForConstantPressure	Boolean
CanBeUsedInEncounters	Boolean
CustomVeterans	See Veteran control below.
DifficultyRating	Float
MaxSpawnCount	Int
MinSpawnCount	Int
Rarity	Float
Significance	String, takes ("Swarmer", "Normal", "Critical", "Critter")
SpawnAmountModifier	Float
SpawnRarityModifiers	*
SpawnSpread	Float
UsesSpawnRarityModifiers	Boolean
UsesVeteranLarge	See Veteran control below.
VeteranClasses	See Veteran control below.

Enemy controls

Fields inside [[]] are special submodules that can be found in the sections that follow.

Name	Type	Comments
Alert	Boolean	If True, the enemy will spawn aggroed to the player. It is True by default in enemies spawned by a wave spawner.
AttackDamageMultiplier	Float	Multiplies an enemy's melee and projectile damage. Can be used with EnemiesNoSync.
Base	ED	The enemy will have the specified ED as base. Check the table in Resources for the vanilla descriptors.
CanPlayerStandOn	Boolean
CaveLeech	[[CaveLeech]]	See the CaveLeech module below for special Cave Leech controls.
Courage	Float
Direct	[Int, Float, Bool, Pcol]	Special control that can expose enemy properties (see example below).
DisplayName	String
DropResource	[[DropResource]]	A special field that allows enemies to drop various resources on death (see below).
Elite	Float | Bool	This field accepts a float number indicating the percentage of Elite enemies that will spawn for that descriptor.
EnemyHealthScaling	String
ForceEliteBase	ED	See Elite variants for all enemies below.
Goomba	[[Goomba]]	Allows killing enemies by jumping on them, see below for options.
Grabber	[[Grabber]]	See the Grabber module below for special Grabber controls.
IsBossFight	Boolean	If True, the enemy will have a boss bar in the player UI similar to the vanilla dreadnoughts. The name in the bar will be the descriptor's DisplayName.
JellyBreeder	[[JellyBreeder]]	See the JellyBreeder module below for special breeder controls.
Heal	Float	A positive number N will heal the enemy N hps. A negative number will do N dps to the enemy. This control has an advanced mode specified below.
HealthMultiplier	Float
HealthRaw	Float
Materials	[[Materials]]	A list of UE4 materials that will be applied to different parts of the enemy. Each enemy is different with regard to how many materials will it accept and how will they be applied, so trial and error is usually needed to get the expected results.
MEV	Special
Movement	[[Movement]]	See the Movement submodule below.
NoSpawnWithin	Float	Removes enemies that spawn within the specified distance of the player, in cm.
Outline	[[Outline]]	Allows setting a permanent outline (as if someone had pinged) to an enemy. See below in the outline section for the options.
Projectile	[[Projectile]]	See Projectiles.
PST_CritBonusDamage	Int	Multiplies the normal damage in case of a Critical Hit (see PST_CritBonusDamage below). Default of 1.2 (20 % bonus).
PST_CritChance	Int	Chance of both bugs dealing Critical Damage to players or the other way around (no way to have only one direction). Defaults to 0 (0 % chance).
PST_DamageFromPlayers	Int	Multiplies all damage sources considered to be from players (including things like temperature shock damage). Defaults to 1.
PST_ExplodeOnDeath	Int	When the enemy dies it explodes as if it was a Volatile Bugs mission.
PST_MovementSpeed	Int	Modifies enemy speed. This is a legacy pawn stat. See the Movement module below for a more customizable module new in CD2.
Resistances	[[Resistances]]	See the Resistances submodule below.
Scale	Float
Spawner	[[Spawner]]	See Spawners below.
ShowHealthBar	Boolean
StaggerImmunityWindow	Float
StaggerDurationMultiplier	Float
Temperature	[[Temperature]]	See the Temperature submodule below.
TimeDilation	Float	Speeds up the enemy's attack and movement. Please note that time-dilating enemies can be a source of desync.
UsesBiomeVariants	Boolean	Enables/disables the biome variants of enemies (eg. Frost Praetorian in Glacial Strata).
WeakpointHP	Float

Goomba

Allows dwarves to damage enemies by jumping/landing on top of the enemy.

Field	Type	Default	Description
Enable	Boolean	True
Cooldown	Float	0.2	Minimum time between successive damage to an enemy from goomba tech
MaxAngle	Float	50	Max angle the dwarf may be away from a straight down hit to still be counted for goomba. At 180, all impact directions count.
SpeedThreshold	Float	300	Speed a dwarf must be moving before an impact is considered goomba'ing
FlattenAmount	Float	0	Amount to flatten an enemy when it is goomba'd between 0 and 0.7
DamageMultiplier	Float	0	DamageMultiplier * (Speed - SpeedThreshold) + FlatDamage = damage dealt. Because speeds can be high (300-1000), this multiplier may be low.
FlatDamage	Float	0	Flat damage dealt regardless of speed. If not set and damagemultiplier not set, defaults to 10k damage.
DamageType	DamageType	DMG_Physical	Most or all DMG_* types supported e.g. DMG_Burn

DropResource

A special field that allows enemies to drop various resources on death.

Field	Type	Default	Description
Enable	Boolean	True	Whether to drop resources when the enemy dies
Resource	String	Nitra	Allowed: Nitra, Gold, Dystrum, Iron, OilShale, RedSugar
Amount	Float	1	Amount of resource to drop, or hp heal amount of red sugar
LaunchStrength	Float	1	Strength of resource dispersal
GoombaOnly	Boolean	False	If true, resources are only dropped if the enemy has been goomba'd.

Example: a bulk detonator that drops oil shale, for use in Escort missions.

{
    "EnemiesNoSync": {
        "ED_Shale_Bulk": {
            "Base": "ED_Spider_ExploderTank",
            "DropResource": {
                "Resource": "OilShale",
                "Amount": 90,
                "LaunchStrength": 1
              }
        }
    }
}

Heal advanced mode

Heal can accept the following advanced settings:

• InitialRate: sets the initial healing if positive or bleed if negative.
• FinalRate: sets the value that will be used after SwitchAfter time has passed.
• SwitchAfter: the time at which the FinalRate will be used. Starts counting on enemy spawn.

Outline special control

This module allows to give a permanent outline to an enemy, as if someone had pinged it. It is usually used to mark dangerous enemies like breeders or ranged threats so you can see them through walls. It accepts two fields: Enable, which accepts a boolean, and Type, which accepts one of the following: Enemy (red outline, default), Friendly, Neutral and Item.

Direct special control

Direct allows to directly change enemy properties as defined in UE4. Many properties that are not directly exposed by CD2 can be changed with Direct. For example:

"ED_Spider_ExploderTank": {
    "Direct": {
        "Int:NumClusterBombs": 200
    }
}

"ED_Spider_Exploder": {
  "Movement": {
    "MaxPawnSpeed": 5,
    "MaxAcceleration": 5,
    "MaxBrakingDeceleration": 10,
    "AlignDirectionSpeed": 10,
    "AlignToTargetMinRequiredAngle": 1,
    "StrafeSpeed": 5
  },
  "Direct": {
    "PCol:Mesh": true
  },
  "CanPlayerStandOn": true,
  "Alert": true
}

"ED_JellyBreeder": {
  "Direct": {
    "Bool:Capsule.bHiddenInGame": false,
    "PCol:Capsule": true
  },
  "CanPlayerStandOn": true
}

In the Direct page you can find a non-exhaustive but fairly complete compilation of all the known direct controls.

Elite variants for all enemies

Setting Elite to true or to some float number will only work directly for those enemies that have a vanilla elite variant:

• Glyphid Grunt Guard
• Glyphid Grunt Slasher
• Glyphid Praetorian
• Glyphid Acid Spitter
• Glyphid Menace
• Mactera Spawn
• Mactera Brundle
• Mactera Tri-Jaw
• Mactera Grabber
• Glyphid Bulk Detonator

For the rest of the enemies, an elite base must be specified by setting ForceEliteBase to some existing ED that has an elite variant. As an example, the following snippet creates an elite septic spreader, which won't work without the ForceEliteBase:

"ED_Elite_Septic_Spreader": {
    "Base": "ED_Spider_Lobber",
    "Elite": true,
    "ForceEliteBase": "ED_Grabber"
}

The type of elite specified as base can modify the characteristics of your custom elite descriptor, feel free to experiment.

Veteran control

Veterans allow some enemies to promote to other enemies. In vanilla the veteran classes are hardcoded (for example, oppressors are praetorians that got promoted with a probability given by the VeteranLarge setting in DifficultySetting). CD2 improves the system by allowing the player to create their own custom veteran classes. There are currently two ways to interact with the veteran system:

• VeteranClasses accepts a list of descriptors that the base descriptor can promote to. VeteranClasses uses VeteranNormal probablities unless UsesVeteranLarge is set to true. The following snippet shows an example:

"DifficultySetting": {
    "VeteranNormal": {
        [
        "Weight": 1,
        "Min": 0.2,
        "Max": 0.2
        ]
    }
},
"Enemies": {
    "ED_Spider_Grunt": {
        "VeteranClasses": [
            "ED_Spider_Shooter",
            "ED_Spider_Spitter"
        ]
    }
}

With these settings, Grunts will promote to acid and web spitters with a 20 % chance each time they spawn. One disadvantage of this approach is that VeternalNormal and VeteranLarge are global.

• The second way is CustomVeterans, which bypasses the VeternalNormal and VeteranLarge settings and lets the user specify the probability directly. The following snippet whould work exactly as the one before, but now the probabilities are contained to the grunt descriptor instead of being global:

"ED_Spider_Grunt": {
     "CustomVeterans": {
        "ED_Spider_Grunt": 0.8,
        "ED_Spider_Shooter": 0.1,
        "ED_Spider_Spitter": 0.1
      }
    }

CustomVeterans also allows specifying a mutator to decide which enemies to spawn, which can give more control. One useful use case is to limit the amount of veterans of a certain type:

"ED_Spider_Grunt": {
      "CustomVeterans": {
        "Mutate": "RandomChoice",
        "Choices": [ "ED_Spider_Buffer", "ED_Spider_Grunt", "ED_Spider_Grunt_Guard", "ED_Spider_Grunt_Attacker" ],
        "Weights": [
          {
            "Mutate": "IfFloat",
            "Value": { "Mutate": "EnemyCount", "ED": "ED_Spider_Buffer" },
            "<": 5,
            "Then": 30,
            "Else": 0
          },
          1,
          1,
          1
        ]
      }
    },

This snippet gives a very high chance of wardens to spawn until there are 5 of them in the map, at which point the probability to get more warden promotions will drop to 0.

Custom materials

CD2 allows specifying a list of Materials in individual enemy descriptors to customize how the enemies look. This feature requires Enemies for clients to be able to see the changes.

Example: create an orange septic.

{
    "Enemies": {
        "ED_Spider_Lobber": {
            "Materials": ["M_Halloween_Light_Orange", "M_Halloween_Light_Orange"]
        }
    }
}

Each enemy has a certain number of material slots. There are hundreds of available materials, but not all of them work when used in enemies. The best way to test and find new materials for your enemies is spawning the enemy in Sandbox Utilities and changing them, and you will be able to see the change in real time. This procedure is explained in this document by @TheBrain. If you wish to leave a slot with the default material, both "" and Default work.

Resistances

Fields for the resistances submodule. These controls can be used to define resistances to all types of damage in the game. DamageMultiplier is the catch-all for all damage types.

Name	Type
InvulnerableToNonDefinedResistances	Boolean
DamageMultiplier	Float
FireDamageMultiplier	Float
CorrosiveDamageMultiplier	Float
ElectricDamageMultiplier	Float
ColdDamageMultiplier	Float
KineticDamageMultiplier	Float
PhysicalDamageMultiplier	Float
ExplosionDamageMultiplier	Float
InternalDamageMultiplier	Float
RadiationDamageMultiplier	Float
PoisonDamageMultiplier	Float
PiercingDamageMultiplier	Float

Movement

The following values are all multipliers with defaults of 1. The following descriptions are provided by @emctwo.

Name	Type	Description
MaxPawnSpeed	Float	Multiplies the maximum speed of the enemy.
StrafeSpeed	Float	Multiplies enemy speed when strafing (enemy movement changes to strafe when they are close to a player).
MinSlowdownAngle	Float	When enemies turn they tend to slow down; this field multiplies the minimum angle for the speed change.
MaxSlowdownAngle	Float	When enemies turn they tend to slow down; this field multiplies the maximum angle for the speed change.
MaxStrafeDistance	Float	The distance to a player where the enemy starts to strafe.
AlignDirectionSpeed	Float	Multiplies how quickly the enemy turns.
FleeSpeedBoostMultiplier	Float	Multiplies enemy speed when feared.
MaxAcceleration	Float	Multiplies how quickly the enemy can change speed.
MaxBrakingDeceleration	Float	Affects how quickly the enemy slows down, which mostly changes how far away from the player they start to slow down.
PathfinderSize	Currently Unsupported
AlignToTargetMinRequiredAngle	Float	The minimal angle required between the enemy's forward direction and the player position to start turning.
PathfinderPreference	Currently Unsupported

CaveLeech

Special controls for cave leeches.

Name	Type	Default
BiteDamage	Float	10
BitesPerSecond	Float	1
MaxDistanceXY	Float	1000
GrapDelay	Float	0.1
TentacleSpeed	Float	600
TentacleRetractSpeed	Float	1100
TentaclePullSpeed	Float	2000
TentacleDropPlayerSpeed	Float	1500
TentacleDropGroundDistance	Float	300
MaxDropPlayerDuration	Float	2
RevivedGracePeriod	Float	10

Grabber

Special controls for grabbers.

Name	Type	Default
WanderingSpeed	Float	250
WanderingAcceleration	Float	1000
ChaseSpeed	Float	750
ChaseAcceleration	Float	4000
CarrySpeed	Float	500
CarryAcceleration	Float	3000
FleeSpeed	Float	800
FleeAcceleration	Float	1000
ExtraUpForce	Float	15
PreventGrabAfterSpawn	Float	3
GrabTime	Float	20
DamageTimeLimit	Float	4
DamageThreshold	Float	25
RevivedGravePeriod	Float	5

JellyBreeder

Special controls for breeders.

Name	Type	Default	Comments
EnemyToSpawn	ED		Can be mutated.
TimeBetweenBursts	Float	20
TimeBetweenEggs	Float	3
CloseToSpawnEggTime	Float	3
EggBurstSize	Int	3
MaxJellies	Int	25
MultiplierOnHighPlayerCount	Float	1.5
SpawnAmount	Int	4
EggName	String
EggMaterial	Material
EggHealth	Float	125
EggSpeed	Float	1.0
EggTime	Float	17

Example:

{
  "Name": "CD2 Beta 6 Test - Breeder Update",
  "Enemies": {
    "ED_GruntBreeder": {
      "Base": "ED_JellyBreeder",
      "DisplayName": "Greeder",
      "Materials": [
        "M_Spider_Grunt_Body_Generic",
        "M_Spider_Grunt_Armor_Guard01",
        "M_Spider_Grunt_Armor_Generic",
        "M_Spider_Grunt_Armor_Guard01",
        "M_Jelly_Breeder_Spike",
        "M_Spider_Grunt_Armor_SlasherClaws"
      ],
      "JellyBreeder": {
        "EnemyToSpawn": "ED_Spider_Grunt",
        "SpawnAmount": 1,
        "TimeBetweenBursts": 40,
        "EggBurstSize": 18,
        "TimeBetweenEggs": 0.5,
        "EggName": "Grunt Egg",
        "EggMaterial": "M_Spider_Grunt_Armor_Guard01",
        "EggHealth": 5,
        "EggTime": 1
      }
    },
    "ED_StalkerBreeder": {
      "Base": "ED_JellyBreeder",
      "DisplayName": "Stalker Breeder",
      "ShowHealthBar": false,
      "Materials": [
        "M_Spider_Stalker_Camouflage",
        "M_Spider_Stalker_Camouflage",
        "M_Spider_Stalker_Camouflage",
        "M_Spider_Stalker_Camouflage",
        "M_Spider_Stalker_Camouflage",
        "M_Spider_Stalker_Camouflage",
        "M_Spider_Stalker_Camouflage"
      ],
      "JellyBreeder": {
        "EnemyToSpawn": "ED_Spider_Stalker",
        "SpawnAmount": 1,
        "TimeBetweenBursts": 40,
        "EggBurstSize": 1,
        "TimeBetweenEggs": 2,
        "EggName": "Stalker Egg",
        "EggMaterial": "M_Spider_Stalker_Camouflage",
        "EggHealth": 80,
        "EggTime": 40
      }
    }
  }
}

Spawner

Spawner is a special submodule that allows any enemy to periodically spawn other enemies with different flexilibity options. It contains the following fields:

Name	Description	Default
OnSpawnDelay	Seconds until the first spawn	2
OnSpawnCount	Initial number of enemies to spawn	0
OnDeathCount	Number of enemies to spawn on death	0
IntervalSpawnCount	Number of enemies to spawn periodically	0
Interval	Time between interval spawns. Min 0.1 seconds	2
ED	The descriptor to spawn
MaxSpawns	Max alive enemies to be spawned by this spawner. Not compatible with EDs with CustomVeteran	200
OnDeathKillSpawns	If true, kill all spawned enemies when the host enemy dies	False
OnlySpawnOnAlert	Will only spawn once the enemy is alerted	True

The following snippet shows a stingtail descriptor with a swarmer module attached. The spawner will spawn 2 swarmers every second until 10 are alive and they will all die when the stingtail is killed:

"ED_Spider_Stinger": {
    "Spawner": {
        "ED": "ED_Spider_Spawn",
        "IntervalSpawnCount": 2,
        "Interval": 1,
        "OnDeathCount": 0,
        "MaxSpawns": 10,
        "OnDeathKillSpawns": true
    }
}

All fields inside the Spawner can be mutated.

Temperature

Special temperature controls to change how enemies react to heat and cold.

Name	Type
DieIfFrozen	Boolean
DieIfBurning	Boolean
IsHeatsourceWhenOnFire	Boolean
OnFireHeatRange	Float
BurnTemperature	Float
DouseFireTemperature	Float
FreezeTemperature	Float
UnfreezeTemperature	Float
WarmingRate	Float
CoolingRate	Float
TemperatureChangeScale	Float
FozenDamageBonusScale	Float
MaxColdSlowdown	Float

Example: the following snippet use the Temperature module to make dreadnoughts ignitable.

{
    "Enemies": {
        "ED_Spider_Boss_Heavy": {
          "Resistances": {"DamageMultiplier": 1.23, "FireDamageMultiplier": 1.2},
          "Temperature": {"BurnTemperature": 100, "DouseFireTemperature": 50}
        },
        "ED_Spider_Boss_TwinA": {
          "Resistances": {"DamageMultiplier": 1.3, "FireDamageMultiplier": 1.2},
          "Temperature": {"BurnTemperature": 100, "DouseFireTemperature": 50}
        },
        "ED_Spider_Boss_TwinB": {
          "Resistances": {"DamageMultiplier": 1.23, "FireDamageMultiplier": 1.2},
          "Temperature": {"BurnTemperature": 100, "DouseFireTemperature": 50}
        }
    }
}
